**Wavelet Parameters**
Ormsby Ricker
Ormsby F1 (hz)	Ormsby F2 (hz)	Ormsby F3 (hz)	Ormsby F4 (hz)	Ricker Peak Frequency (hz)
*	*	*	*	*

**Trace Parameters**
Output Sample Interval (ms)	DFT Window Start (ms)	DFT Window End (ms)	DFT Cosine Taper %	Show samples	db spectra
*	*	*	*

**Impedance Model**
# THIS IS AN EXAMPLE MODEL TO DEMONSTRATE INPUT # signifies that the rest of the line is an optional comment 200 1 # Time (ms) to 1st horizon background acoustic impedance value pair 204 2 # Time (ms) to 2nd Horizon acoustic impedance between horizons 1 and 2 210 1 # Time (ms) to 3rd Horizon acoustic impedance between horizons 2 and 3 230 2 # Time (ms) to 4th Horizon acoustic impedance between horizons 3 and 4 # Click the "Submit" Button to show filtered traces and spectra *
* required field.
